How To Edit Floor Plan View Range In Revit

I d have to start over.

How to edit floor plan view range in revit.

Draw the sketch as necessary then click finish. Everything cut by the pink line like in the image below will display in thick lines. To set the view range of a view open your properties pane and click the edit button next to view range under the extents group. Change the view depth to show elements below the bottom clip plane.

The horizontal planes are top cut plane and bottom. Define the display settings for projection lines using the object styles or the override graphics in view functions in revit. You can do this by using plan region. You can find this tool in view tab create panel plan views drop down plan region.

The back clip plane is defined by the view depth parameter which is part of the view s view range properties. When you create a plan view you can choose floor plan structural or rcp. It s the only property you can. You will need to define the plan region using sketch tool.

Establish or change the horizontal planes that control an object s visibility in plan views. Go to the floor plan view and click in the view range menu in the instance properties. The top and bottom clip planes represent the topmost and bottommost portion of the view range. In the view range dialog modify view range properties as necessary.

Top cut plane bottom offset from bottom primary range and view depth. Open a plan view. In order to enable different view representations make sure that the option show family pre cut in plan views in the structural beam family is unchecked. I didn t realize it until i was done with the plan.

It s probably not a bid deal but i d like to change it if it were an easy fix. For revit structure plan views include structural plan views detail plan views and callout plan views. So you need to define different view range for that particular area. Alternatively enter vr on the keyboard.

Follow these steps in order to get the desired display. Every plan view has a property called view range also known as a visible range. This opens the view range dialog where you can adjust values for top cut plan bottom and view depth but what does all of this mean. The view range is a set of horizontal planes that control object visibility and display in the view.

In a floor plan view the key parameters are cut plane and bottom. The cut plane is a plane that determines at what height certain. View depth is an additional plane beyond the primary range. I used floor plan for a structural plan.

The following elevation shows the view range of a plan view. Set a level and a height offset for each of these parameter. On the properties palette locate the view range parameter and click edit. I m thinking it can t be done.

Now when you click the boundary you created above you will see view range in properties palette.
